EVA 135-HS

Benefits :

  • Improves indoor air quality by removing dust, fumes & odours.
  • Improves productivity in industries through 100% fresh, clean & cool air.
  • Low Capex & Opex.
  • Cost Effective and Energy Efficient.
  • Consumes upto 80% less electricity than refrigerated air conditioning.
  • Green & Sustainable Evaporative Technology.
  • Strong protection from electric faults.

Product Features :

  1. High static air pressure and long distance air delivery .
  2. Robust wired Remote controller .
  3. In-built single phase preventer ,short circuit and overload protection.
  4. High efficiency Honey Comb Cooling Pads with higher saturation levels.
  5. Heavy duty Submersible type water pump for continuous water supply.
  6. Rust free Stainless steel tank of large capacity
  7. Non-clogging type water distributor to ensure uniform flow of water over pads.
  8. 100% copper wounded electric motor for durability and Aluminium casing to ensure fast heat dissipation.
  9. AMCA Certified Forward curved DIDW Centrifugal Fan.
  10. Easy to Operate and Maintain.
  11. Pre-dust filters to ensure dust free fresh air and longer life of pads.
  12. Float valve to ensure continuous water supply and maintain set water level.
  13. Powder Coated GP sheet strong cabinet
  14. Customisable to variable speed and to any capacity upto 60000 CFM



Specs/Model EVA –135-HS
Discharge Type Side
Airflow (m³/hr) 13500
Static Pressure (mmwg) 40
Power (kw) 1.5
Power Resource (V/Hz) 415 / 50
Fan Type Centrifugal Blower
Fan Speed 3-Phase, Single Speed
Vent Size (L x W) mm 545 X 465
Noise (dBA) ≤70
Back Pad Size (L x H x W) 535 X 845 X 200 (2 Nos.)
Side Pad Size (L x H x W) 855 X 845 X 100 (2 Nos.)
Dimension (L x W x H) 1250 X 1235 X 1270
Net Weight (KG)
Operating Weight (KG)
Intelligent Clean No
Water Lack Protection No
Controller Wired Remote
Pre-Dust Filter YES
Tank Capacity (Litre) 140
Evaporation Efficiency 85%

Additional information


Direct Evaporative Cooling, Indirect Evaporative Cooling, Industrial Ductable Cooler, Industrial Portable Cooling, Residential & Commercial
